TBH BF9 BF10 treatment fume extractor

Protect yourself, your staff and patients with the TBH system for the extraction and filtering of fumes produced by medical and aesthetic treatments.

Model
Quantity

help_outlineAsk about product
TBH BF9 BF10 treatment fume extractor

TBH BF9 BF10 treatment fume extractor



  100% secure payment methods

Cards - PayPal - Bank Transfer - ApplePay

  Are you a Doctor or a Professional?

Sign in here to obtain reserved price list

  Fast shipping throughout Europe

We use only premium couriers

Protect yourself, your staff and patients with the TBH smoke extraction and filtration system. In laser surgery, particles with a size of around 0.1μm - 2μm are generated which, being biological, can be dangerous if inhaled.
Laser aerosols (LGAC = Laser Generated Air Contaminant) consist of microscopic parts of human tissue, removed from the tissue in the form of vapor or gas.
The dangers are represented by microorganisms such as bacteria, viruses and fungi. These have a particle size of approximately 2μm and can be fully breathed in resulting in deposition in the lungs. The risk of acute infection for user personnel and patients is very high.
Please keep in mind that the surgical face mask does not offer protection against microscopic particles. TBH BF9/BF10 was developed around the patient to protect him from airborne infections.
Available the BF9 model with traditional brush motor and the BF10 model with quieter (62 dBA) long-lasting brushless motor.
The TBH BF9/BF10 vacuum cleaner is characterized by a suction capacity of 200 m3/h and a separation degree of 99.95% (H13).
It is equipped with a wide range of (optional) accessories.
The BF9 SET-D and BF10 SET-D filtering and suction systems have no applied parts according to EN 60601-1, as the devices are designed and the suction arm is positioned in such a way as not to touch the patient during suction. In order to guarantee the greater safety required in the medical field, it is possible to carry out electrical safety checks according to EN 62353, as required by EN 60601-1.



AREAS OF APPLICATION

  • Cosmetic surgery interventions (skin removal, hair removal, alteration of the epidermis)
  • HF surgery
  • Dental Medicine
  • Endoscopy

CHARACTERISTICS

  • Simple filter change from above
  • Suction arm with four optional air vents
  • Optional foot pedal operation
  • Electronic flow regulation and status visualization functions via display
  • Differential pressure indicator for monitoring filter saturation
  • Can be equipped with prefilter
90389
